DWK Duran GLS80 Stirred Reactor Cap, with Anchor-Shaped Stirrer Spindle

The DWK Duran GLS 80 Stirred Reactor Cap with Anchor-Shaped Stirrer and Spindle is designed for seamless integration with GLS 80 stirred reactor systems. Crafted from high-quality materials including polypropylene (PP), PTFE, PEEK, and stainless steel, this cap features a robust anchor-type stirrer for enhanced mixing performance when driven by a standard magnetic stirrer (up to 500 rpm).

Key Features:

• Brand: DWK Duran
• System Compatibility: GLS 80 stirred reactor systems (500, 1,000, or 2,000 mL bottles)
• Stirrer Type: Anchor-shaped magnetic stirrer with spindle
• Materials: Cap – PP; Shaft – PTFE/PEEK; Contact surfaces – stainless steel
• Operating Speed: Up to 500 rpm (not recommended above 400 rpm for liquids >10 mPa·s)
• Ports: Multiple threaded ports (2 × GL 14 and 2 × GL 18) for media and gas handling
• Autoclavable: Yes
• Anchor Stirrer Diameter: 62 mm; Shaft diameter: 6 mm; Height: 62 mm
• Sterility & Flexibility: Compatible with sterile transfer systems (tubing 1.6–12 mm OD)

This DWK Duran accessory offers flexible, sterile-compatible mixing in closed reactor systems, enhancing efficiency and performance in fermentation, dissolution, and other mixing applications.

Frequently Asked Questions

1. What is the DWK Duran GLS80 Stirred Reactor Cap, with Anchor-Shaped Stirrer Spindle used for?

It is designed for seamless integration with GLS 80 stirred reactor systems. Crafted from high-quality materials including polypropylene (PP), PTFE, PEEK, and stainless steel, this cap features a robust anchor-type stirrer for enhanced mixing performance when driven by a standard magnetic stirrer (up to 500 rpm).

2. Is this product suitable for seamless integration with GLS 80 stirred reactor systems?

Yes. It is designed for seamless integration with GLS 80 stirred reactor systems, and offers an operating speed of up to 500 rpm (not recommended above 400 rpm for liquids >10 mPa·s) and an anchor stirrer diameter of 62 mm; Shaft diameter: 6 mm; Height: 62 mm to support this kind of work.

3. What operating speed and anchor stirrer diameter does this product have?

It has an operating speed of up to 500 rpm (not recommended above 400 rpm for liquids >10 mPa·s) and an anchor stirrer diameter of 62 mm; Shaft diameter: 6 mm; Height: 62 mm.

4. What system compatibility and stirrer type does this product offer?

It offers GLS 80 stirred reactor systems (500, 1,000, or 2,000 mL bottles), anchor-shaped magnetic stirrer with spindle, cap – PP; Shaft – PTFE/PEEK; Contact surfaces – stainless steel and multiple threaded ports (2 × GL 14 and 2 × GL 18) for media and gas handling.
